Passport js: How to use it to handle local authentication in Node js

A common requirement when building a web app is to implement a login system. So users can authenticate themselves before gaining access to protected views or resources. Luckily for those building Node apps, there’s a middleware called Passport js. It can be dropped into any Express-based web application to provide authentication mechanisms in only a few commands.

Passport is authentication middleware for Node.js. Extremely flexible and modular, Passport js can be unobtrusively dropped in to any Express-based web application. A comprehensive set of strategies support authentication using a username and password, Facebook, Twitter, and more.

In this article, we will demonstrate how to use Passport js to implement local authentication with a MongoDB back end.

passport js
Passport js

Before we start with Passport js

First of all, you need to have Node and MongoDB installed on your machine. You can install Node by heading to the official Node download page and grabbing the correct binaries for your system.

Alternatively, you can use a version manager. It is a program that allows you to install multiple versions of Node and switch between them at will.

MongoDB comes in various editions. The one we’re interested in is the MongoDB Community Edition.

Creating the Project

Once all of the prerequisite software is set up, we can get started.

We’ll begin by creating the folder for our app and then accessing that folder on the terminal:

mkdir AuthApp
cd AuthApp

To create the node app, we’ll use the following command:

npm init

You’ll be prompted to provide some information for Node’s package.json. Just keep hitting Return to accept the default configuration (or use the -y flag).

Setting up Express

Now we need to install Express. Go to the terminal and enter this command:

npm install express

We’ll also need to install the body-parser middleware which is used to parse the request body that Passport js uses to authenticate the user. And we’ll need to install the express-session middleware.

Let’s do that. Run the following command:

npm install body-parser express-session

When that’s done, create an index.js file in the root folder of your app and add the following content to it:


const express = require('express');
const app = express();


const bodyParser = require('body-parser');
const expressSession = require('express-session')({
  secret: 'secret',
  resave: false,
  saveUninitialized: false

app.use(bodyParser.urlencoded({ extended: true }));

const port = process.env.PORT || 3000;
app.listen(port, () => console.log('App listening on port ' + port));

First, we require Express and create our Express app by calling express(). Then we define the directory from which to serve our static files.

The next line sees us require the body-parser middleware, which will help us parse the body of our requests. We’re also adding the express-session middleware to help us save the session cookie.

Then, we use process.env.PORT to set the port to the environment port variable if it exists. Otherwise, we’ll default to 3000, which is the port we’ll be using locally. This gives you enough flexibility to switch from development, directly to a production environment where the port might be set by a service provider like.

That’s all for the Express setup. Now it’s on to setting up Passport js.

Setting up Passport js

First, we install Passport js with the following command:

npm install passport

Then we need to add the following lines to the bottom of the index.js file:


const passport = require('passport');


Here, we require passport and initialize it along with its session authentication middleware, directly inside our Express app.

Creating a MongoDB Data Store

Since we’re assuming you’ve already installed Mongo, you should be able to start the Mongo shell using the following command:


Within the shell, issue the following command:

use MyDatabase;

This simply creates a datastore named MyDatabase.

Leave the terminal there; we’ll come back to it later.

Connecting Mongo to Node with Mongoose

Now that we have a database with records in it, we need a way to communicate with it from our application. We’ll be using Mongoose to achieve this. Why don’t we just use plain Mongo? Well, as the Mongoose devs like to say ,A href=””>on their website:

Mongoose will simply make our lives easier and our code more elegant. Let’s go ahead and install it with the following command:

npm install mongoose

We’ll also be using passport-local-mongoose, which will simplify the integration between Mongoose and Passport js for local authentication. It will add a hash and salt field to our Schema in order to store the hashed password js and the salt value.

This is great, as passwords should never be stored as plain text in a database. Let’s install the package:

npm install passport-local-mongoose

Now we have to configure Mongoose. Hopefully you know the drill by now: add the following code to the bottom of your index.js file:


const mongoose = require('mongoose');
const passportLocalMongoose = require('passport-local-mongoose');

  { useNewUrlParser: true, useUnifiedTopology: true });

const Schema = mongoose.Schema;
const UserDetail = new Schema({
  username: String,
  password: String

const UserDetails = mongoose.model('userInfo', UserDetail, 'userInfo');

Here we require the previously installed packages. Then we connect to our database using mongoose.connect and give it the path to our database. Next, we’re making use of a Schema to define our data structure. In this case, we’re creating a UserDetail schema with username and password fields.

Finally, we add passportLocalMongoose as a plugin to our Schema. This will work part of the magic we talked about earlier. Then, we create a model from that schema. The first parameter is the name of the collection in the database.

The second one is the reference to our Schema, and the third one is the name we’re assigning to the collection inside Mongoose.

That’s all for the Mongoose setup. We can now move on to implementing our Passport js strategy.

Implementing Local Authentication

And finally, this is what we came here to do! Let’s set up the local authentication. As you’ll see below, we’ll just write the code that will set it up for us:




There’s quite some magic going on here. First, we make passport use the local strategy by calling createStrategy() on our UserDetails model — courtesy of passport-local-mongoose — which takes care of everything so that we don’t have to set up the strategy. Pretty handy.

Then we’re using serializeUser and deserializeUser callbacks. The first one will be invoked on authentication, and its job is to serialize the user instance with the information we pass on to it and store it in the session via a cookie.

The second one will be invoked every subsequent request to deserialize the instance, providing it the unique cookie identifier as a “credential”.


Now let’s add some routes to tie everything together. First, we’ll add a final package. Go to the terminal and run the following command:

npm install connect-ensure-login

The connect-ensure-login package is middleware that ensures a user is logged in. If a request is received that is unauthenticated, the request will be redirected to a login page.

Now, add the following to the bottom of index.js:

/* ROUTES */

const connectEnsureLogin = require('connect-ensure-login');'/login', (req, res, next) => {
  (err, user, info) => {
    if (err) {
      return next(err);

    if (!user) {
      return res.redirect('/login?info=' + info);

    req.logIn(user, function(err) {
      if (err) {
        return next(err);

      return res.redirect('/');

  })(req, res, next);

  (req, res) => res.sendFile('html/login.html',
  { root: __dirname })

  (req, res) => res.sendFile('html/index.html', {root: __dirname})

  (req, res) => res.sendFile('html/private.html', {root: __dirname})

  (req, res) => res.send({user: req.user})

At the top, we’re requiring connect-ensure-login. We’ll come back to this later.

Next, we set up a route to handle a POST request to the /login path. Inside the handler, we use the passport.authenticate method, which attempts to authenticate with the strategy it receives as its first parameter — in this case local.

If authentication fails, it will redirect us to /login, but it will add a query parameter — info — that will contain an error message. Otherwise, if authentication is successful, it will redirect us to the '/' route.

Then we set up the /login route, which will send the login page. For this, we’re using res.sendFile() and passing in the file path and our root directory, which is the one we’re working on — hence the __dirname.

The /login route will be accessible to anyone, but our next ones won’t. In the / and /private routes we’ll send their respective HTML pages, and you’ll notice something different here. Before the callback, we’re adding the connectEnsureLogin.ensureLoggedIn() call. This is our route guard.

The Client

The client should be quite simple. We’ll create some HTML pages and a CSS file. Let’s begin with the home page, or index. In your project root, create a folder called html and add a file called index.html. Add the following to it:

<!DOCTYPE html>
<html lang="en">
  <meta charset="UTF-8" />
  <title> Home </title>
  <link rel="stylesheet" href="css/styles.css">

  <div class="message-box">
    <h1 id="welcome-message"></h1>
    <a href="/private">Go to private area</a>

    const req = new XMLHttpRequest();
    req.onreadystatechange = function () {
      if (req.readyState == 4 && req.status == 200) {
        const user = JSON.parse(req.response).user;
        document.getElementById("welcome-message").innerText = `Welcome ${user.username}!!`;
    };"GET", "http://localhost:3000/user", true);

Here we have an empty h1 tag where we’ll place our welcome message and, below that, a link to /private. The crucial part here is the script tag at the bottom where we’ll handle getting the username to create the welcome message.

This is divided into four parts:

  1. We instantiate the request object using new XMLHttpRequest().
  2. We set the onreadystatechange property with the function that will be called after we get our answer. We’re checking if we got a successful response and if so, we parse the response, get the user object. And we find the welcome-message element to set its innerText to our user.username.
  3. We open() the GET request to the user URL and we set the last parameter to true to make it asynchronous.
  4. Finally, we send() the request.

Now we’ll create the login page. As before, in the HTML folder create a file called login.html and add the following content to it:

<!DOCTYPE html>
<html lang="en">
  <title> Login </title>
  <link rel="stylesheet" href="css/styles.css">

  <form action="/login" method="post">
    <div class="title">
    <div class="field">
      <input type="text" name="username" />
      <br />
    <div class="field">
      <input type="password" name="password" required />
    <div class="field">
      <input class="submit-btn" type="submit" value="Submit" required />
    <label id="error-message"></label>

    const urlParams = new URLSearchParams(;
    const info = urlParams.get('info');

    if(info) {
      const errorMessage = document.getElementById("error-message");
      errorMessage.innerText = info; = "block";

On this page, we have a simple login form, with username and password fields, as well as a Submit button. Below that, we have a label where we’ll display any error messages. Remember, these are contained in the query string.

The script tag at the bottom is far simpler this time. We’re instantiating a URLSearchParams object passing the property, which contains the parameters string in our URL.

Then we use the URLSearchParams.get() method, passing in the parameter name we’re looking for.


Let’s set up the private page now. Again, create a file in the HTML folder with the name private.html and add the following content:

<!DOCTYPE html>
<html lang="en">
  <title> Private </title>
  <link rel="stylesheet" href="css/styles.css">

  <div class="message-box">
    <h2>This is a private area</h2>
    <h3>Only you can see it</h3>
    <a href="/">Go back</a>

Super simple. Just a simple message and a Go back link which takes us back to the homepage.

That’s it for the HTML, but as you probably noticed, we’re referencing a CSS file the head tags. Let’s add that file now. Create a folder called css in the root of our project and add a styles.css file to it, with the following content:

body {
  display: flex;
  align-items: center;
  background: #37474F;
  font-family: monospace;
  color: #cfd8dc;
  justify-content: center;
  font-size: 20px;

.message-box {
  text-align: center;

a {
  color: azure;

.field {
  margin: 10px;

input {
  font-family: monospace;
  font-size: 20px;
  border: none;
  background: #1c232636;
  color: #CFD8DC;
  padding: 7px;
  border: #4c5a61 solid 2px;
  width: 300px;

.submit-btn {
  width: 100%

.title {
  margin: 10px 0px 20px 10px

#error-message {
  color: #E91E63;
  display: block;
  margin: 10px;
  font-size: large;
  max-width: fit-content;

This will make our pages look decent enough. Let’s check it out!

Grab a terminal pointing to the project root and run the following command:

node index.js

Now navigate to http://localhost:3000/ in your browser. You should be redirected to the login page. If you try to go to http://localhost:3000/private, it should redirect you to the login page again. There’s our route guard doing its job.

Press Ctrl + C in the terminal window to stop our server. Then head back to the index.js file and, at the bottom of the file, add the following lines:


UserDetails.register({username:'paul', active: false}, 'paul');
UserDetails.register({username:'jay', active: false}, 'jay');
UserDetails.register({username:'roy', active: false}, 'roy');

This uses the passport-local-mongoose register method to salt the password js for us. We just have to pass it in in plain text.

Now we run node index.js. The users will be created. You should comment those last lines now.

Remember the MongoDB shell terminal we left open? Go back to it and type:


This should show your three users and, as you can see, the salt and hash now occupy a good portion of the space on the terminal.

That’s all we need for the app to work.

Passport js: Next Steps

We only added the necessary modules for this app to work — nothing more, nothing less. For a production app, you’ll need to add other middleware and separate your code in modules. You can take that as a challenge to set up a clean and scalable environment and grow it into something useful!

The first and easiest thing you should try is adding the logout, using Passport’s req.logout() method.

Then you could try implementing a register flow. You’ll need a registration form and a route to talk to. You should use the UserDetails.register() we added earlier as a template. For email confirmation, you should check out nodemailer.

Another thing you could do is try to apply these concepts to a single page application. Perhaps using Vue.js and its router.

To sum up with Passport js

Well, we’re finally at the end. In this article, we learned how to implement local authentication using Passport js in a Node.js application.

I hope you enjoyed this tutorial, and maybe got some inspiration for your next project. Check our Vue js development services
